The Avatar HD Goggles were designed with a robust set of features at a great price, offering versatility, lightweight comfort and vibrant, immersive FPV experience. With Dual HD OLED 1080p Displays, Built-In Focus Adjustment, HDMI Output, and more, these Goggles won't disappoint.
FEATURES:
- Integrated HD DVR
- HD Video Output via USB-C Connector & HDMI Output
- On/Off Power Button & adjustable Anti-Fog Ventilation
- Focus adjustment without the need to install corrective lenses
- Customizable fit with optional faceplate pad accessories
- HD OLED 1080p Dual Micro Displays with 46° field of view
- Four antennas for great reception
- Supports Canvas Mode with full Betaflight, Kiss, Inav, Ardu OSD display
- Ranging mode available to display the distance between the drone and goggles in real time, in case the drone is lost due to long distance flights
SPECIFICATIONS:
Goggles:
- Model: Avatar goggles
- Communication Frequency: 5.725-5.850GHz
- Transmitter Power (EIRP): FCC:<30dBm;CE:<14dBm;SRRC:<20dBm; MIC:<25dBm
- I/O Interface: Type-C,microSD card slot, DC 5.5*2.1mm
- IPD Mechanical Range: 58-70mm
- IPD Visual Range: 54-74mm
- Adjustable Focus Range: +2 to -6 Diopter
- FOV: 46°
- Screen Resolution: 1920x1080
- Screen Refresh Rate: 1080/100Hz
- Screen Size: 0.49"1nch
- Screen Material: OLED
- HDMI Output: Support
- Power Input: 7-21V (2S-5S)
- SD Card Support: 256G
- Weight: 300 Grams
Omni-Directional Antennas:
- Model: Redbird
- Polarization: LHCP
- Bandwidth: 5.6GHz-6.0GHZ
- Average Gain: 1.9dBi
- Radiation Efficiency: ≥97%
- VSWR: ≤1.3
- Cross-Polar Rejection: -15to-30dB
- Connector: RP-SMA
- Dimensions: H24.8mm*R15.3mm
- Weight: 4.2g
INCLUDES:
(1) Walksnail Avatar HD Goggles
(1) Carrying Case
(1) XT60 Power Cable
(1) Goggle Head Strap
(1) Lens Cleaning Cloth
(2) Redbird Antennas
(2) Patch Antennas
MORE INFO:
Robust Features
HD 1080p OLED Dual Micro Displays
Canvas Mode
Lightweight and Comfortable
Focus Adjustment
HDMI Output
Ranging Mode
