Traxxas 1/10 Raptor-R 4X4 VXL-4S Ultimate Truck (Brushless / ARR) IN-STORE ONLY

*Due to the restrictions implemented by Traxxas, this item is only available at our retail store for In-Store Purchase, or online if In-Store Pickup is selected.

The Traxxas Ford Raptor R 4X4 VXL Ultimate is a 1/10 scale short course truck that blends rugged performance with stunning realism. Powered by a 4S-capable Velineon 540XL brushless motor and VXL-4s ESC, it rockets past 60+ mph while maintaining control through Traxxas Stability Management (TSM).

It's officially licensed Ford body features clipless mounting, integrated LED lighting, and molded scale details. With heavy-duty driveline components, aluminum upgrades, and real-time telemetry via the included wireless module, this truck is built for serious speed and scale style.

FEATURES:

• Velineon 540XL Brushless Motor: Delivers extreme 4S power with 2400KV output for 60+ mph speeds.
• VXL-4s Waterproof ESC: Supports 2S–4S LiPo batteries with built-in telemetry and selectable BEC voltage.
• Traxxas Stability Management (TSM): Enhances control and acceleration on low-traction surfaces.
• Extreme Heavy Duty Driveline: Reinforced driveshafts, steel gear differentials, and 6mm axles.
• Aluminum Upgrades: Includes 6061-T6 aluminum C-hubs, steering blocks, and rear hub carriers.
• GTR Shocks: Aluminum oil-filled shocks with 70% more oil capacity than standard Ultra Shocks.
• TQi 2.4GHz Radio System: Includes wireless module and factory-installed telemetry sensors.
• High-Torque Metal Gear Servo: Waterproof with aluminum center case and up to 486 oz-in torque.
• Clipless Pro Scale Body: Ford-licensed with molded bumpers, grille, tailgate, and side mirrors.
• LED Lighting: Integrated into front and rear bumpers for night driving.
• Extended Chassis: Longer wheelbase for improved stability and scale proportions.
• BFGoodrich All-Terrain KO2 Replica Tires: Oversized 114mm diameter with authentic tread and lettering.
• Ford Replica Wheels

REQUIRED:

(1) 2-4S LiPo Battery
(1) LiPo Battery Charger
(4) AA Batteries for Transmitter

SPECIFICATIONS:

• Model#: 101177-4

• Model Type: Short Course Truck
• Model Speed: 60+ mph with 4S LiPo (sold separately)
• Model Skill Level: 2
• Scale: 1/10
• Weight: 6.62 pounds (3.00 kg)
• Length: 24.98 inches (637 mm)
• Width: 11.63 inches (289 mm)
• Front Track: 11.63 inches (289 mm)
• Height: 8.91 inches (226 mm)
• Rear Track: 11.63 inches (289 mm)
• Wheelbase: 15.11 inches (384 mm)
• Center Ground Clearance: 2.05 inches (52 mm)
• Drive System: Shaft-driven 4WD with Torque-Biasing Center Drive
• Differentials: Hardened steel bevel, sealed, limited slip
• Gear Pitch: 32 pitch
• Servo: 2275 high-torque waterproof
• Radio System: TQi™ 2.4 GHz 2-channel with wireless module
• Battery Compartment Specs: 165 mm × 50 mm × 23/26 mm
• Motor Type: 540XL 2400KV sensorless brushless
• Shaft Size: 5 mm
• Motor Connector Type: Traxxas 6.5 mm bullet connectors
• ESC Name: Velineon VXL-4s
• ESC Input Voltage: 2S–4S LiPo (7.4 V – 16.8 V)
• ESC Case Size: 2.40″ × 2.09″ × 1.42″ (61 mm × 53 mm × 36 mm)
• ESC Weight: 4.20 ounces (119 g)
• BEC Voltage: Selectable 6.0 or 7.4 volts
• ESC Motor Connectors: Traxxas 6.5 mm bullet connectors
• ESC Battery Connectors: Traxxas High-Current Connectors
• Thermal Protection: Two-stage thermal shutdown
• ESC Ports: RX input, auxiliary fan connector

HELPFUL LINKS:

• User Manual

INCLUDES:

(1) Traxxas Raptor R 4X4 VXL-4S Ultimate Electric Off-Road Truck
(1) Quick Start Guide
(1) TQi™ 2.4 GHz radio system
(1) High-quality maintenance tools
