Flywoo GOKU F405 ERVT / 5A / 400mw VTX / 25x25 AIO Flight Controller w/ ELRS (BlHeli_S / 1S)

The Flywoo GOKU F405 ERVT 1S 5‑in‑1 AIO is a lightweight, all‑in‑one board built for high‑performance 1S whoops and micro quads, combining an F405 processor, 5A ESC, 400 mW ELRS receiver, OSD, and power management into a compact, efficient package. It delivers strong signal range, clean video, and reliable power delivery while keeping builds simple and ultra‑light.

FEATURES:

• F405 flight controller for fast, responsive processing
• Built‑in 400 mW ELRS 2.4GHz receiver for long‑range, low‑latency control
• 5A BLHeli‑S ESC supporting 1S brushless micro motors
• Integrated 5‑in‑1 design (FC, ESC, RX, OSD, power management)
• Onboard analog OSD for clean, configurable video overlay
• Ultra‑lightweight layout optimized for whoops and micro quads
• Plug‑and‑play wiring pads for simple, compact builds
• High‑efficiency power filtering for stable video and flight performance

SPECIFICATIONS:

• MCU: STM32F405

• Gyro: BMI270

• Input Voltage: 1S LiPo
• Receiver: Built‑in ELRS 2.4GHz (up to 400 mW output)

• VTX: Integrated 400 mW analog VTX

• ESC: 4‑in‑1 BLHeli‑S, 5A continuous (1S)

• BEC Output: 5V

• OSD: Built‑in analog OSD

• UART Ports: Multiple UARTs available

• Mounting Pattern: 25.5 × 25.5 mm (M2)

• Dimensions: Ultra‑compact micro AIO layout

• Weight: Lightweight design for 1S whoops and micros

• Integrated Functions: FC + ESC + ELRS RX + VTX + OSD

INCLUDES:

(1) GOKU F405 ERVT 1S 5A 5-in-1 400mw ELRS AIO
(1) A30 power cable
(1) JST-0.8 3-pin 50mm camera cable
(1) Flywoo Black box connector cable
(4) 1.25mm 3-Pin Vertical Straight Socket
(4) M2x6.6 Shock-Absorbing Ball

NOTES:

• Manufacturer upgrades, alterations, and processor/firmware changes are frequently made without prior notice. Exact specifications, photos, and links cannot be guaranteed.
