Flywoo Goku F7 Pro V2 30x30 Flight Controller (6 Uarts / ICM42688 / 3-6S)
Flywoo Goku F7 Pro V2 30x30 Flight Controller (6 Uarts / ICM42688 / 3-6S) is backordered and will ship as soon as it is back in stock.
Pickup available at RC-N-Go in S. Jacksonville, FL
Usually ready in 1 hour
Flywoo Goku F7 Pro V2 30x30 Flight Controller (6 Uarts / ICM42688 / 3-6S) is backordered and will ship as soon as it is back in stock.
Flywoo Goku F7 Pro V2 30x30 Flight Controller (6 Uarts / ICM42688 / 3-6S)
The Flywoo GOKU F722 Pro V2 30x30 Flight Controller delivers fast, stable performance with its STM32F722 processor and ICM42688 gyro. Featuring plug‑and‑play sockets, 16MB black box, dual BECs, and DJI O4 compatibility, it offers easy installation, reliable power, and professional‑grade control for freestyle and racing FPV builds.
FEATURES:
-
STM32F722 processor (216MHz) for fast and precise flight control
-
ICM42688 gyro for stable and responsive handling
-
Standard 30x30mm mounting size for compatibility with most FPV frames
-
Supports up to 8 motor outputs with dual 4‑in‑1 ESC sockets
-
Plug‑and‑play socket design simplifies wiring and maintenance
-
Optional solder pads for flexible installation
-
16MB black box for flight data logging and tuning
-
Integrated 10V/3A and 5V/3A BECs to power VTXs, cameras, and peripherals
-
Immersion gold PCB process for durability under high current and heat
- DJI O4 Air Unit, Caddx Walksnail & HDZero compatibility for seamless digital FPV integration
SPECIFICATIONS:
- Part#: FW19003495
- Product Name: GOKU F722PRO
- Input Voltage: 7.4V-26V/2-6S LiPo
- BF Flight Controller Firmware: FLYWOO F722PRO
- INAV Firmware: FLYWOO F7
- MCU: STM32F722
- Gyroscope: MPU6000 \ ICM42688
- OSD: AT7456E
- Barometer: DPS310 / SPL06
- Black Box: 16MB
- UARTS: 1/2/3/4/5/6
- BEC: 10V3A/5V3A
- Flight Controller Size: 37mm x 37mm x 8mm
- Mounting Holes: M3 30x30mm
- Weight: 9.9g
INCLUDES:
(1) Flywoo Goku F7 Pro V2 30x30 Flight Controller
(1) FC&ESC Connection Cable
(1) Buzzer Connection Cable
(1) GPS Connection Cable
(1) DJI O4 Connection Cable
(1) Receiver Connection Cable
(4) M3 Shock-Absorbing Ball
(7) M3 Rubber Ring
(1) Analog VTX Connection cable
(1) Camera Connection Cable
NOTES:
-
Manufacturer upgrades, alterations, and processor/firmware changes are frequently made without prior notice. Exact specifications, photos, and links cannot be guaranteed.
- Please make sure your DJI video transmitter's cable matches the flight controller's pinout.
