HobbyWing QUICRUN 2850 / 3400KV Brushless Motor (3mm Shaft / 2-3S)

The Hobbywing QuicRun 2850 is a compact, smooth‑running brushless motor for 1/14–1/18 scale vehicles, offering efficient power, reliable performance, and multiple KV options for easy tuning.

FEATURES:

• High‑efficiency sensorless brushless design for smooth, responsive power
• Precision‑balanced rotor for reduced vibration and improved reliability
• Compact 28mm × 50mm size ideal for 1/14–1/18 scale vehicles
• Durable construction with high‑quality bearings and materials
• Multiple KV options to match different speed and torque needs
• Low‑maintenance operation with excellent heat dissipation
• Wide compatibility with mini buggies, trucks, and on‑road platforms

SPECIFICATIONS:

• Part#: 30404804
• Motor Type: Sensorless Brushless
• Input Voltage: 2S–3S LiPo
• KV Option: 3400Kv
• Motor Size: 28mm (diameter) × 50mm (length)
• Shaft Diameter: 3.175mm
• Shaft Length: 15mm
• Poles: 4‑pole rotor
• Bullet Connectors: 3.5mm

HELPFUL LINKS:

• QuicRun Motor Manual

INCLUDES:

(1) HobbyWing QUICRUN 2850 / 3400KV Brushless Motor
