The Skystars F405 HD V2 Flight controller supports the DJI air unit with a dedicated 10V output and traditional analog video OSD. It features a high-speed F4 processor and has 6 UARTS for connecting various peripherals and bigger soldering pads for easier solder work.
SPECIFICATIONS:
- Input Voltage: 3-6S LiPo (11.1V~22.2V)
- MCU: STM32F405RGT6 168MHz
- IMU: BMI270 (SPI)
- OSD: Betaflight OSD & DJI HD OSD (UART6)
- UARTS: 6
- Receiver: ELRS/SBUS/IBUS/DSM
- Barometer: YES
- Buzzer Pad: YES
- CURR Pad: YES
- BEC: 5V 2A & 10V 2A(Max 3A)
- Blackbox: 16MB
- Betaflight Target: SKYSTARS F405
- INAV Target: SKYSTARSF405HD
- Mounting Holes: 30.5mm/M3
- Weight: 0.21oz (6g)
HELPFUL LINKS:
INCLUDES:
(1) Skystars F405 HD V2 Flight Controller
(3) 8-Pin Cables
(2) 8-Pin Housing Connectors
(4) M3 Grommets (Red)
NOTES:
- Manufacturer upgrades, alterations, and processor/firmware changes frequently made without prior notice. Exact specifications, photos, and links cannot be guaranteed.
