Introducing the new F722 HD Pro 60A Stack This 6S-capable F7 Stack fits all frames with a 30x30 mounting pattern.
SPECIFICATIONS:
Flight Controller:
- Input voltage: 3-6S
- BEC: 5V/10V 3A max dual-channel BEC supports stable power supply on the sky side of DJI
- LDO 3.3V: Max. 250mA
- MCU: STM32F722RGT6 216MHz
- Gyroscope: BMI270
- Baro: Bmp280
- OSD: Betaflight SPI OSD DJI HD OSD (UART6)
- Black box: 16MB
- Uarts: UART 1/2/3/4/5/6
- PWM outputs: x4
- 3x LEDs for FC STATUS (Blue, Green) and 3.3V indicator(Red)
- USB: Type-C (USB2.0)
ESC:
- Support 128K Dshot1200, Dshot600, Dshot300, Dshot150, Oneshot125, Multishot, PWM control signal
- Power supply voltage: 3-6S (12-26V)
- Continuous working current: 60A
- No built-in 5V BEC output
- Firmware: BLHELI 32 ESC
- Screw hole spacing: 30.5*30.5MM
- Aperture: 4MM
- Weight: 14.6g
HELPFUL LINKS:
INCLUDES:
(1) Skystars F722 HD Pro3 + KO60 Stack
(8) M4 to M3 Silicone Grommets
(2) JST-SH1.0 8-Pin Cable (4cm)
(1) JST-GH-6P Cable for DJI Port (10cm)
NOTES:
- Manufacturer upgrades, alterations, and processor/firmware changes are frequently made without prior notice. Exact specifications, photos, and links cannot be guaranteed.
