TBS Crossfire Nano Long Range Tx Module

Regular price $79.99

Shipping calculated at checkout. See Shipping Policy for shipping times.

The Crossfire module, shrunk down to its pure essence for long-range transmission up to 40km (25 miles)! This module is not only for FPV racers that need extra distance but it's also great for its ultra-low latency.



COMPATIBILITY:

  • FrSky X9 Lite Radio Transmitter (with included adapter)
  • FrSky X-Lite Radio Transmitter
  • Jumper T-Lite Radio Transmitter



FEATURES:

  • Long-range, adaptive and robust remote control system for your aircraft
  • Immune to on-board noise
  • Two-way communication link with real-time link vitals and telemetry
  • Self-healing & frequency hopping (DSSS, FHSS)
  • Adaptive bandwidth control and range optimization
  • Super easy binding and configuration via built-in display of your R/C
  • Low latency, 150Hz update rate (3x faster than typical RC links) control
  • Two receiver models: 8 port Diversity Rx, 4 port Mini-receiver (4g weight!)
  • 8 or 12ch output via SBUS/PPM/CRSF on both receivers
  • Ability to fly with multiple friends at the same time (10 or more)
  • Selectable RF power from 25mW to 1W (local restrictions apply)
  • Transmitter LED shows link health
  • Micro-receiver for smaller drones. Smaller than you think!
  • Software updates via RF Link



SPECIFICATIONS:

  • Frequency Bands: 868MHz (EU, Russia) / 915MHz (USA, Asia, Australia)
  • Input Voltage: 6.0 - 13V
  • Connector: USB-C
  • Power Output: 25mw to 1w
  • Dimensions: 64 x 42 x 25mm (Nano TX module size)
  • Weight: 1.69oz (48g)



HELPFUL LINKS:



INCLUDES:

(1) TBS Crossfire Nano Tx
(1) TBS Crossfire Stock Tx Antenna V2
(1) X9 Lite Back Case
