Traxxas High Trail Edition™ TRX-4® models are the biggest and baddest trucks on the trail and now classic Blazer fans have reason to celebrate. The 1972 Chevrolet® K5 Blazer gets the full High Trail treatment with a big, lifted stance and beautifully detailed body. The factory-installed Long Arm Lift Kit boosts the Blazer’s ground clearance by more than an inch with larger 2.2″ wheels and tires to conquer the roughest terrain. K5 Blazer High Trail Edition delivers more of what you crave—extreme all-terrain capability, stunning scale looks, and Traxxas-Tough™ durability.
FEATURES
- LED-ready headlights and tail lights
- Clipless design for smooth body appearance
- Factory-Installed Long Arm Lift Kit
- Accommodates oversize 2.2″ wheels and tires
- Steel gears
- Full-time shaft-driven 4-wheel drive
- Steel front CV driveshafts
- Innovative Battery Compartment - Accommodates different height batteries
- Two-speed high/low range with remote shifting
- Pre-mounted 2.2″ Canyon Trail tires with trail-tuned foam inserts
- Sealed Ball Bearings
REQUIRED:
(1) 2S or 3S LiPo Battery or 6-7 Cell NiMH with Traxxas High-Current Connector
(1) LiPo Battery Charger
SPECIFICATIONS:
- Part# 92086-4
- Length: 20.67 inches (525mm)
- Front Track: 10.63 inches (270mm)
- Rear Track: 10.63 inches (270mm)
- Weight: 7.26lbs (3.30kg)
- Height (overall): 11.22 inches (285mm)
- Wheelbase: 12.28 inches (312mm)
- Front Shock Length: 4.33 inches (110mm)
- Rear Shock Length: 4.33 inches (110mm)
- Front Tires (pre-glued): 5.3 x 2.14 inches (135 x 54mm)
- Rear Tires (pre-glued): 5.3 x 2.14 inches (135 x 54mm)
- Front Wheels: 2.2 x 1.34 inches (56 x 34mm)
- Rear Wheels: 2.2 x 1.34 inches (56 x 34mm)
- Electronic Speed Control: XL-5 HV
- Motor (electric): 21T Reverse Rotation
- Steering Servo: 2075X Metal Gear
- Transmitter: TQi™ 2.4 GHz 4-Channel Transmitter
- Receiver: 6533
- Gear Ratio (internal):
- Differential Type: 4 Gear, Remote Locking
- Gear Pitch: 32P
- Transmission: 2-speed High/Low, Remote Shifting
- Steering: Chassis Mounted Servo
- Chassis Type: Steel Ladder Frame with Nylon Composite Crossmembers
- Skill Level: 1
- Input voltage: 6–7 Cells NiMH, 2–3s LiPo
- Case Size: 1.23” W x 2.18” D x 1.04” H
- Weight: 2.6oz (74g)
- Motor Limit: 21-turns (550 size)
- On Resistance Forward: 0.004 Ohms
- On Resistance Reverse: 0.004 Ohms
- BEC Voltage: 6.0 VDC
- BEC Current: 1A
- Power Wire: 14 Gauge / 5”
- Input Harness Wire: 26 Gauge / 14.5”
- PWM Frequency: 1700Hz
- Low Voltage Detection (LVD): 2-Stage indicators, switchable (on or off)
- Thermal Protection: Thermal Shutdown
- Single-button setup: Yes, Traxxas EZ-Set®
HELPFUL LINKS:
- K5 Trail Blazer Manual
- Body Assembly Exploded View
- Body Cage Assembly Exploded View
- Chassis Assembly Exploded View
- Front Assembly Exploded View
- Modular Assembly Exploded View
- Rear Assembly Exploded View
- Transmission Assembly Exploded View
INCLUDES:
(1) Traxxas 1/10 TRX-4 Chevrolet K5 Trail Blazer Crawler
(1) TQi 2.4GHz 4-channel radio system
(1) Quality tool set
(1) Quick Start Guide
NOTES:
- This vehicle available for Curbside Pickup Only
