Introducing the new Mamba MK4 FC 4th Gen Flight Controller, featuring a redesigned pad style to increase pad area by 30% and pad spacing by 100% to help reduce soldering errors and associated failures.
SPECIFICATIONS:
- MCU: 168MHz STM32F405
- GYRO: MPU6500
- OSD: Yes (AT7456E)
- Blackbox: 16M Flash Memory
- Barometer: SPL06
- Uarts: 6-Set
- I2C: Yes
- F.Port: Yes
- RSSI: No
- Buzzer Pad: Yes
- CURR Pad: Yes
- ESC Signal: 6 Set
- ESC Soft: Dshot300/600/1200
- ESC Telemetry: Yes
- Power Led: Yes
- LED Controller: BF LED
- AIR UNIT Port: Yes
- BF LED: Yes
- WIFI: No
- VTX Switch: Yes
- Receiver Protection: Yes
- BEC Protection: Yes
- TVS Protection: Yes
- BEC: 3.3V 0.5A & 5V 2.5A & 9V 2A
- Software: Betaflight
- Input: 3~6S LiPo (12.6~25.2V)
- Mounting Size: 20mm x 20mm, M2/M3
- Size: 29.0 x 29.5 x 6.5mm
- Weight: 6.0 Grams
INCLUDES:
(1) Diatone Mamba F405 Mini MK4 Flight Controller
(5) M2 Silicone Dampeners
(5) M3 Silicone Dampeners
(5) M2 ESC Grommets
(5) M3 ESC Grommets
(1) 8-Pin FC Cable
(2) 8-Pin Cable
(1) 6-Pin Air Unit Cable
NOTES:
- Manufacturer upgrades, alterations, and processor/firmware changes frequently made without prior notice. Exact specifications, photos and links cannot be guaranteed.
